Z-NANO Tool Setting Probe

Robust and extremely precise – Tool setting probe with linear working principle for monitoring of smallest tools.

Tool Measurement

Hardwired

Linear Working Principle

Wear-Free Measuring Mechanism

Tool Breakage Detection

Tool Length Measurement

Axes Compensation

Benefit:

Extremely fast tool breakage detection

No subsequent damage due to tool breakage

Fast ROI

No-wear, optoelectronic  measurement mechanism

Compact and robust design

Linear working principle

Due to the linear working principle the probe provides a minimal and torque-free measuring force. Even the most sensitive and smallest tool diameters can be measured extremely precise.
